EYECRYL PHAKIC TORIC

Hydrophilic Acrylic Foldable Phakic Toric Intraocular Lens with Delivery System

EYECRYL PHAKIC TORIC Intraocular Lens (IOLs) are monofocal hydrophilic acrylic foldable single-piece posterior chamber intraocular lens. These IOLs are designed to be surgically implanted into the posterior chamber of the eye in ciliary sulcus in front of natural crystalline lens for correction or reduction of myopia and myopia with astigmatism.

FEATURES

92% of eyes within ±0.50 D of refractive astigmatism
Excellent rotational stability
For correction or reduction of myopia and myopia with astigmatism
Effective reduction in subjective manifest astigmatism
Predictable, safe & effective outcomes
Aspheric optic
100% SE predictability within ±1.00 D

TECHNICAL SPECIFICATIONS

MATERIAL	Hydrophilic Acrylic CQ UV
OPTIC TYPE	Toric Aspheric
OPTIC SIZE	6.50 mm
EFFECTIVE OPTIC SIZE	4.65 mm to 5.50 mm
OVERALL SIZE	11.0 mm to 14.0 mm
REFRACTIVE INDEX	1.462
DIOPTER RANGE	+8.0 D to -25.0 D (with 0.5D step)
CYLINDER POWER RANGE	0.5D to 5.0D (in 0.5D step)
IMPLANTATION SITE	Posterior Chamber
TORIC AXIS ON IOL OPTIC	0°, 30°,60°,90°,120° & 150°
STERILIZATION	Steam

Models Available	Lens overall size	Diopter range	Cylindrical Correction
PC120T	12.00 mm	+8.0 D to -25.0 D (in 0.5D step)	0.5D to 5.0D (in 0.5D step)
PC125T	12.50 mm	+8.0 D to -25.0 D (in 0.5D step)	0.5D to 5.0D (in 0.5D step)
PC130T	13.00 mm	+8.0 D to -25.0 D (in 0.5D step)	0.5D to 5.0D (in 0.5D step)
PC130T	13.50 mm	+8.0 D to -25.0 D (in 0.5D step)	0.5D to 5.0D (in 0.5D step)

Model PC110T PC115T PC120T PC125T PC130T PC135T PC140T

Size (mm) 11.00 mm 11.50 mm 12.00 mm 12.50 mm 13.00 mm 13.50 mm 14.00 mm
